G90 GNSS Receiver — Dual Cameras
Dual cameras, laser distance meter and AR stakeout in a complete GNSS receiver.
The G90 provides high-precision positioning through multi-constellation support (GPS, GLONASS, BEIDOU, GALILEO, QZSS, IRNSS, SBAS) with 1,408 channels. It features RTK with IMU tilt compensation up to ±60°, positioning accuracy of 8 mm + 1 ppm horizontally and 15 mm + 1 ppm vertically. The device includes dual cameras (5 MP front with 76° FOV, 2 MP rear), a green laser distance meter (2 mm accuracy, 30 m range), and AR stakeout technology. IP67-rated rugged design, shock resistant to 2 m, operating temperature -40 °C to +65 °C, 64 GB built-in memory, 4G modem, Bluetooth 5.2, Wi-Fi, and 7000 mAh battery supporting 10 hours operation.
Highlights
- Dual cameras · 5 MP front (76° FOV) + 2 MP rear
- Green laser distance meter — 2 mm accuracy, 30 m range
- AR stakeout technology
- 1,408 channels · all major constellations + IRNSS + SBAS
- IMU tilt compensation up to ±60°
- RTK Horizontal 8 mm + 1 ppm · Vertical 15 mm + 1 ppm
Technical specifications
| Battery | 7000 mAh built-in |
| Cellular | 4G LTE/UMTS/GSM, Nano SIM |
| Channels | 1,408 |
| Rear camera | 2 MP |
| Connectivity | Bluetooth 5.2, Wi-Fi |
| Front camera | 5 MP, 76° FOV |
| Constellations | GPS, GLONASS, BEIDOU, GALILEO, QZSS, IRNSS, SBAS |
| Internal radio | UHF 2 W, up to 10 km (optimal) |
| Operating time | Up to 10 hours |
| Drop resistance | 2 m |
| Internal memory | 64 GB |
| Protection rating | IP67 |
| Laser distance meter | 2 mm accuracy · 30 m range |
| IMU tilt compensation | ±60° |
| Operating temperature | –40 °C to +65 °C |
| RTK vertical accuracy | 15 mm + 1 ppm |
| RTK horizontal accuracy | 8 mm + 1 ppm |
